Key Features
● Support device - based rate limitation and bandwidth control
● In compliant with IEEE802.3ah &ITU-T G.984.x standard
● Wi - Fi series meet 802.11a/b/g/n/ac technical standards
● Up to 20KM transmission distance
● Support data encryption,group broadcasting, port Vlan separation ,etc.
● Support Dynamic Bandwidth Allocation(DBA)
● Support ONU auto - discovery/Link detection/remote upgrade of software;
● Support port VLAN configuration
● Support power - off alarm function ,easy for link problem detection
● Support Qos configuration
● Support port binding
● Support port flowarding
● Support ACL to configure data packet filter flexibly
● Specialized design for system breakdown prevention to maintain stable system
● Support software online upgrading
● Support TR069 for ACS(Auto Config Server)
● Support PPPoE/DHCP Server/IPTV/POTS/NAT
Voice Service Functions
● With the heartbeat function, support the main producing soft exchange platform;
● Support high / low speed mode transparent transmission, T38 two fax;
● Support high-speed Modem (56Kbps) dial access; support RFC2833 and redundant RFC2833, ringing, MD5 certification, call forwarding, call waiting, the hotline, alarm clock, abbreviated dialing and other value-added services;
● Support SIP (compatible with IMS),H.248,MGCP three VolP protocol, and the soft switch platform the mainstream can be good intercommunication;
● Support POTS port GR909 line test function;
● Support dynamic PPPoE, DHCP and static lP;
● Support lTU-TG.711,G.723.1,G.729 and other three kinds of compression algorithm; echo cancellation conforming to ITU-T G.168-2002, an echo canceller forthe longest 128ms;
● 7*24 hour call loss is less than or equal to 0.01%;
● Support 2 POTS interface and the three party call, three party support local mixing;
WIFl Features(2.4G/5G)
● Wi-Fi Specification lEEE 802.11n compliant,2.4 GHz/5G
● Full IEEE 802.11b/g/ac legacy compatibility with enhanced performance
● Two-stream spatial multiplexing up to 866 Mbps PHY data rates
● Support multi-SSID (Maximum 4 SSID)
● Support automatic channel selection
● Support hide SSID
● Support wireless security of 64/128 bit WEP,802.1x,WPA and WPA2
Technical Parameter
| User interface | 4 10/100/1000M RJ45 port 2*POTS 1*USB 2.4GWiFi/5GWiFi |
| PON | EPON&GPON mode adaptive lnterface Type:SC-UPC/SC-APC Security: ONU authentication mechanism Network coverage radius: 20KM GPON: upstream 1.25Gbps /downstream 2.5Gbps Optical receive sensitivity:-7dBm~-28dBm Continuous light power: 0.5dBm~+5dBm EPON: upstream 1.25Gbps /downstream 1.25Gbps Optical receive sensitivity:-7dBm~-27dBm Continuous light power: 0dBm~4dBm |
| Ethernet | 4*10/100/1000Mauto-negotiation Full/half duplex mode RJ45 connector Auto MDI/MDI-X 100m distance |
| Size | 160mm(L)×112mm(W)×32mm(H) |
| Environment | Operating temperature:0°C～60℃ Operating humidity:10%～85% non-condensing Storage temperature:-40℃~80℃ Storage humidity:5%~95% non-condensing |
| Power supply | 12V1.5A DC power interface size:2.1mm/5.5mm |
| Power Consumption | <12W |
| POTS Port | 2*RJ11 Max 1km distance Balanced Ring, 55V RMS |
| Man | WEB/TELNET/TR069/OMCI/OAM |
Product Interfaces and Indicators Definitions
POWER
| Power status | On: The ONU is power on Off: The ONU is Power off |
PON
| ONU Register | On: Success to register to OLT Blinking: In process of registering to OLT Off: Fail to register to OLT |
LOS
| Optical Signals | On: Optical link lower than receiver sensitivity Off: Optical in normal |
LAN
| LAN Port status | On: Ethernet connection is normal Blinking: Data is being transmitted Off: Ethernet connection is not set up |
2.4G
| WIFI | On: Wi - Fi function Opens Blinking: Data is being transmitted Off: wi - Fi function closes |
5G
| WIFI | On: Wi - Fi function Opens Blinking: Data is being transmitted Off: wi - Fi function closes |
NET
| lnternet status | On: ONU can access internet Off: ONU can not access internet |
VOIP1
| VOIP1 status | On: Voice account Registered Off: Voice account not Registered |
VOIP2
| VOIP2 status | On: Voice account Registered Off: Voice account not Registered |
